12V RGB Push Button Switch 22mm Vandal-Proof IP67

22mm Vandal-Proof RGB Push Button Switch | Epoxy-Sealed Cable & IP67 Waterproof

Available Models

• ON/OFF (Latching) - PB22W1L: Latching switch for permanent control applications
• (ON)/OFF (Momentary) - PB22W2L: Momentary switch for temporary activation control

This illuminated push button 22mm is available in two configurations adapted to different usage requirements:

• Latching push button switch: Press once to turn ON, press again to turn OFF (ideal for boat dashboard switch)
• Momentary push button: The switch stays ON only while pressed (perfect for automotive push button start systems)

Additionally, the RGB LED indicator (Green, Red, and Blue) can be used as a status light for boat electronics or industrial panel control, providing instant state feedback when integrated into your system.

Key Features of the Vandal-Proof Switch

Additional technical characteristics:

• Over 180 symbols available – Complete customization for custom gaming PC projects
• Common cathode LED switch wiring – Simplified installation for various applications
• 20A capacity – Supports high-intensity applications
• IP67 Waterproof – Complete resistance to water and dust
• Anti-vandal design – Ideal for demanding environments and marine equipment

🛠️ How to Use this Vandal-Proof Panel Mount Switch

This vandal-proof RGB push button switch is designed for intuitive operation and complete customization. It features a robust press-activation mechanism and an interchangeable symbol system, making it perfect for electronic control in various applications.

🔹 Illuminated Push Button Operation

• Latching Mode (PB22W1L): ON/OFF activation by press - ideal for boat dashboard
• Momentary Mode (PB22W2L): Activation only during press - perfect for engine start button

🔹 LED Indicator Functionality

• Integrates high-brightness RGB LEDs (Green, Red, and Blue)
• Status indicator function with positive input signal
• Single color selection according to your wiring and application
• Perfect for state signaling on marine or industrial equipment

🔹 Symbol Customization

This illuminated switch comes with over 180 interchangeable symbols, allowing complete adaptation to your custom projects and professional applications.

Symbol change procedure:

1. Select a symbol suitable for your application
2. Remove the protective film from the chosen symbol
3. Insert the symbol into the switch's transparent lens
4. Secure the lens by pressing until you hear the "click" lock

⚡ Wiring Guide: Common Cathode LED Switch

This LED indicator switch uses an optimized common cathode wiring system, meaning that all LED colors share a common ground connection (White wire). This design simplifies installation and ensures maximum compatibility with 12V-24V systems.

🔹 Panel Mount Switch Wiring Diagram
