Circuit Breaker & On/Off Switch (Manual Reset) - Panel Mount

SKU: BSC60I
37.50€
37.50€
Rated Current: 60A
Subtotal: 37.50€

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

THERMAL CIRCUIT BREAKER + SWITCH ON/OFF (Manual Reset) - Panel Mount

🛡️ Ultimate Protection for Your Marine Electrical Systems

Keep your marine electrical systems safe and operational with our 2-in-1 Circuit Breaker + Switch On/Off. Designed for high performance and reliability, this manual reset circuit breaker is perfect for demanding marine environments.

🌟 Key Features:

🔄 2-in-1 Functionality: Combines a circuit breaker and an on/off switch, providing dual protection and control in one compact unit.

🔌 Panel Mount Design: Easily integrates into your control panel for a clean, professional installation.

🛠️ Manual Reset: Provides added safety by requiring a manual reset after an overload or short circuit, ensuring that issues are addressed before power is restored.

High Amp Ratings: Available in 60A, 120A, 250A, and 300A, supporting a wide range of high-current applications.

🌊 Weatherproof (IP66): Built to withstand harsh marine environments with IP66 rating, offering protection against water and dust.

📏 Compact Size: Fits seamlessly into your existing panel setup without taking up excessive space.

🚤 Ideal Applications:

  • Marine Equipment: Essential for bilge pumps, winches, and other critical marine applications.
  • Electrical Equipment Protection: Safeguards sensitive electronics and prevents damage from power surges.
  • Industrial Control Systems: Ensures smooth operation of heavy-duty machinery and equipment.
  • Power Distribution Panels: Integral for maintaining power integrity and reliability in distribution systems.

🔩 Specifications:

  • Voltage Compatibility: 12V, 24V, 48V
  • Mounting Type: Panel Mount (à encastrer)
  • Stud Size: M5
  • Dimensions: 86.4x59.1x46.4mm -  Ø54.05mm / 3.40x2.33x1.83inch - Ø0.22

🛠️ Easy Installation:

With its straightforward panel mount design, this circuit breaker + switch combo can be easily installed, ensuring a secure and reliable connection. The M5 stud size allows for versatile mounting options, making it suitable for various marine and industrial applications.



Ref

BSC60I

BSC120I

BSC200I

BSC250I

BSC300I

Reset

Manual Reset

Interrupt Rating

5KA @ 14Vdc

3KA @ 24Vdc

1.5KA @ 48Vdc

Amps

60A

120A

200A

250A

300A

ON/OFF Cycles

> 3K cycles @ 48Vdc

Waterproof

IP66

Sud size

M5 (8.5nm) - Stainless

Working temperature

-40°C-85°C

Compliance

SAE J553 UL1500, SAE J1171, Ignition protected, ABYC E11

Product size

87.9x59.1x48.2mm

Center hole

41.2x65.4mm

How to use :

Discover tips, tricks, and detailed instructions on using our product in our dedicated blog post. Learn about setup, operation, and optimization to get the most out of your purchase.


Link to the blog
